TIMM Mini Bite Grounding Clamp

TIMM Mini Bite Grounding Clamp

Applications: Small cans, canister, buckets, funnels; filling and pouring on work and laboratory benches;  earthing of very small plant components or when using small drum pumps or stirrers

Min. order quantity (without cables): 10 pieces


excl. VAT plus shipping costs

Add to quote


  • Very compact clamp for grounding of small items such as cans, containers, tools or equipment, usually used when handling flammable liquids on work or laboratory benches
  • Strong pliers spring ensures best biting force
  • Extra hardened teeth to penetrate even thin coating and product deposits
  • Protection of teeth against wear and tear when not in use
  • Integrated strain relief prevents the cable from being torn off from the clamp during work
  • TIMM Medium Bite can be ordered individually or ready for use with connected grounding cable
  • Due to the compact size of the TIMM Mini Bite we recommend to use a straight highly flexible copper grounding cable (non-coiled)

Contact Person

Do you have questions about the product?

Do you have questions about the product or the TIMM-Onlineshop? Please contact me!

Svenja Steppe
Sales Engineer & PM Dust Ex

write an E-Mail
+49 (0) 40 248 35 63 – 0

Technical Specifications

Name / type:TIMM Mini Bite
Features:Stainless steel V2A (1.4301)
Very compact and robust construction
Hardened stainless steel teeth
Both teeth on one side
Tip protection in rest position (opposite relief bores)
Strong spring force
Cable connection with strain relief
Size:Leg length 60 mm
Opening width 15 mm
Max. cable cross-section:Connect grounding cables up to 4 mm²
Cable connection to clamp with lug M3
Ex Zones:Zone 1, 21
Ex Marking:Ex II 2 G Ex h IIA / IIB / IIC T6 Gb
Ex II 2 D Ex h IIIC T80°C Db
