TIMM Basic Bite Grounding Clamp

TIMM Basic Bite Grounding Clamp

Applications: Small to medium sized drums, barrels, containers, canisters, buckets, oil cans, filling funnels and small plant components

Min. order quantity (without cables): 10 pieces


excl. VAT plus shipping costs

SKU TBBASIC Categories , ,
Add to quote


  • Simple grounding clamp for basic protection against electrostatic charges in rough work environments
  • Well balanced spring force
  • Less sensitive to damage caused by falling in contrast to comparable die-cast clamps
  • TIMM Basic Bite can be ordered individually or ready for use with connected grounding cable
  • We recommend to use this clamp with our very strong coiled steel stranded cable

Contact Person

Do you have questions about the product?

Do you have questions about the product or the TIMM-Onlineshop? Please contact me!

Svenja Steppe
Sales Engineer & PM Dust Ex

write an E-Mail
+49 (0) 40 248 35 63 – 0

Technical Specifications

Name / type:TIMM Basic Bite
Features:Stainless steel V2A (1.4301)
Robust construction
One tooth on each side
Strong spring force
Size:Leg length 132 mm
Opening width 25 mm
Max. cable cross-section:Connect grounding cables up to 4 mm²
Cable connection to clamp with lug M3
Ex Zones:Zone 1, 21
Ex Marking:Ex II 2 G Ex h IIA / IIB / IIC T6 Gb
Ex II 2 D Ex h IIIC T80°C Db
